Aluminum , Aluminum Slitting Line-Recoiler
| serial number | nameof production line | applicable materials | sheet thickness (mm) | sheet width (mm) | coil inner diameter (mm) | outer diameter of coil (mm) | coil weight (T) | width precision (mm) | number of longitudinal cuts(pc) | longitudinal shear width(mm) | speed (m/min) | toutal power (K≤) | mechanical general ground (m) |
| 1 | 1.0*360 | general mechanical floor: carbon steel, stainless steel, aluminum and various specialties | 0.1-1.0 | 100-360 | φ250/φ300/φ400/φ500 | ≤φ1200 | ≤2.5 | ≤±0.05 | ≤12 | ≥6 | ≤60 | ≤45 | 8*3 |
| 2 | 1.2*500 | 0.15-1.2 | 100-500 | φ300/φ500 | ≤φ1200 | ≤3 | ≤±0.05 | ≤14 | ≥20 | ≤120 | 80 | 8*3 |
| 3 | 2.0*650 | 0.2-2.0 | 150-650 | φ508/φ610 | ≤φ1500 | ≤6 | ≤±0.05 | ≤16 | ≥20 | ≤180 | 96 | 11*4 |
| 4 | 2.0*850 | 0.25-2.0 | 200-850 | φ508/φ610 | ≤φ1500 | ≤10 | ≤±0.05 | ≤16 | ≥20 | ≤180 | 96 | 11*4 |
| 5 | 2.0*1000 | 0.2-2.0 | 300-1000 | φ508/φ610 | ≤φ1500 | ≤15 | ≤±0.05 | ≤24 | ≥20 | ≤180 | 120 | 11*5 |
| 6 | 2.0*1250 | 0.15-2.0 | 500-1250 | φ508/φ610 | ≤φ1500 | ≤15 | ≤±0.05 | ≤24 | ≥20 | ≤180 | ≤160 | 12*4.6 |
| 7 | 2.0*1600 | 0.2-2.0 | 500-1600 | φ508/φ610 | ≤φ1500 | ≤20 | ≤±0.05 | ≤32 | ≥20 | ≤200 | 240 | 22*7 |
| 8 | 3.0*650 | 0.2-3.0 | 200-650 | φ508/φ610 | ≤φ1500 | ≤15 | ≤±0.05 | ≤12 | ≥20 | ≤150 | 180 | 22*7 |
| 9 | 3.0*1250 | 0.3-3.0 | 500-1250 | φ508/φ610 | ≤φ1500 | ≤15 | ≤±0.05 | ≤12 | ≥20 | ≤180 | 205 | 22*6.5 |
| 10 | 3.0*1600 | 0.4-3.0 | 600-1600 | φ508/φ610 | ≤φ1500 | ≤25 | ≤±0.05 | ≤24 | ≥30 | ≤120 | 230 | 23*8.5 |
Note: The above standards are for reference only, and parameters
can be determined according to customer needs.
Steel plate cutting and striping unit can provide a variety of deep
processing to provide protection, is the pursuit of higher material
utilization rate in modern industrial production
The high-performance PLC reliable hydraulic pneumatic system, high
strength, high stiffness of the structure design.
According to the thickness of the processing sheet we also divided
the cutting unit into thin plate series cutting unit and thick
plate series cutting unit, thin plate series cutting unit according
to the difference in structure and divided into machinery
Foshan Hong Zhong Machinery Equipment Co.,Ltd. is the introduction
of Taiwan technology, a company set design, development,
production, sales, trade and service in one of the metal flat
horizontal shear machine, slitting machine manufacturer slitting
machine, High speed flying shear machine. Hongzhong machine located
in China stainless steel trade center - Foshan, east to GuangZhou,
south of HongKong & Macao. With be richly endowed by nature
geographical advantage; strong technical force; efficient
management team and strong sales service ability, the company
developed rapidly, product and services of radiation throughout the
country and exported to Southeast Asia, the Middle East, India and
Pakistan, South America around.
Hongzhong machinery has for many years engaged in the metal
industry of flying shear machine, leveling shearing and slitting
machine research and development, management, production and sales
of professional team.Company strict implementation of ISO9001 2008
quality management system standard, after many years of innovation
and development, set up across the country and abroad sales
system.Excellent quality and perfect after sale service system to
win a large number of loyal customers for the company, the more
highly recognition industry and authority.
“Integrity, the pursuit of excellence, integrity and win-win
cooperation, sustainable development,” Hong Zhong Machinery with
you hand in hand, for having the courage to social and economic
development, create a better future.
